Care Glass Cutting Machine SOLD

The Seller purchased this glass cutting machine but no longer requires it for their needs. The machine is still in its original manufacturing wrapping and stored in a machinery storage facility in the northeast. The Seller is open to all offers, and the current asking price is lower than what the seller originally paid after shipping. Videos of machine before it was shipped to storage on request.

This particular model of glass cutting machine requires manual loading of glass, but it can automatically optimize the layout and cut glass in straight lines and irregular shapes. The machine is compatible with the standard G code of the Italian OPTIMA optimization software, which enables versatility in file processing in different formats.

In addition, the machine has several advanced features, including fault diagnosis and alarm function, which can record and display any problems during production. The machine also has an automatic glass edge finding and positioning function that can accurately detect the position and deflection angle of the glass and adjust the cutting path of the cutter head accordingly, thus improving efficiency. Finally, the machine has an intelligent special-shaped scanning function that can scan special-shaped objects and generate graphics for profiling cutting. The cutting wheel is German-made.

Specification:
Glass Thickness Range: 3~19mm
Max Glass Size: 3660mm x 2440mm
Cutting Speed: 0-180m/min
Floor Print: 5700mm L x 4060mm W x1630mm H
Table Height: 880mm (Additional Adjustment 30mm +or-)
